Gas disc for silo Piston vibrator FP series (cylindrical)
FP-12
Aluminum shell, corrosion resistant, with special grease
Product features
? Power, a small amount of lubrication, quiet
? Frequency 2450-9120HZ
? Vibration force 30-1200N
? Continuous adjustable parameters (adjustable pressure)
? Maximum operating temperature: 150℃
? Can be customized 200℃
? Suitable for extreme bad environment
? Vibrating table
? Filter sieve
? Storage bin emptying
? Dispersing and compacting bulk material
? Preventing material hanging on the wall of bin
? Driving conveying device and discharging groove
| Piston reciprocating | Working pressure | Frequency/Min | Force | Air consumption | Shell length | Shell diameter | Mounting hole |
| Model | (MPa) | (HZ) | (N) | (ANR) | (MM) | (MM) | Metric |
| FP-12-S | 0.2～0.6 | 5120～8120 | 30～58 | 0.6～19 | 71 | 34 | M8 |
| FP-12-M | 0.2～0.6 | 4800～6705 | 35～77 | 0.7～20 | 81 | 34 | M8 |
| FP-12-L | 0.2～0.6 | 3950～5380 | 33～80 | 1.0～21 | 94 | 34 | M8 |
