Gas disc for silo Piston vibrator FP series (cylindrical)
FP-25
Aluminum shell, corrosion resistant, with special grease
Product features
? Power, a small amount of lubrication, quiet
? Frequency 2450-9120HZ
? Vibration force 30-1200N
? Continuous adjustable parameters (adjustable pressure)
? Maximum operating temperature: 150℃
? Can be customized 200℃
? Suitable for extreme bad environment
? Vibrating table
? Filter sieve
? Storage bin emptying
? Dispersing and compacting bulk material
? Preventing material hanging on the wall of bin
? Driving conveying device and discharging groove
| Piston reciprocating | Working pressure | Frequency/Min | Force | Air consumption | Shell length | Shell diameter | Mounting hole |
| Model | (MPa) | (HZ) | (N) | (ANR) | (MM) | (MM) | Metric |
| FP-25-S | 0.2～0.6 | 3500～5550 | 120～410 | 13～75 | 98 | 50 | M12 |
| FP-25-M | 0.2～0.6 | 3050～4165 | 145～500 | 15～80 | 116 | 50 | M12 |
| FP-25-L | 0.2～0.6 | 2350～3620 | 180～600 | 19～90 | 136 | 50 | M12 |
