Gas disc for silo Piston vibrator FP series (cylindrical)
FP-35
Aluminum shell, corrosion resistant, with special grease
Product features
? Power, a small amount of lubrication, quiet
? Frequency 2450-9120HZ
? Vibration force 30-1200N
? Continuous adjustable parameters (adjustable pressure)
? Maximum operating temperature: 150℃
? Can be customized 200℃
? Suitable for extreme bad environment
? Vibrating table
? Filter sieve
? Storage bin emptying
? Dispersing and compacting bulk material
? Preventing material hanging on the wall of bin
? Driving conveying device and discharging groove
| Piston reciprocating | Working pressure | Frequency/Min | Force | Air consumption | Shell length | Shell diameter | Mounting hole |
| Model | (MPa) | (HZ) | (N) | (ANR) | (MM) | (MM) | Metric |
| FP-35-S | 0.2～0.6 | 3760～5795 | 270～1050 | 25～160 | 98 | 65 | M12 |
| FP-35-M | 0.2～0.6 | 2980～4580 | 260～1100 | 24～140 | 116 | 65 | M12 |
| FP-35-L | 0.2～0.6 | 2450～2595 | 250～1200 | 33～140 | 136 | 65 | M12 |
